RG-8 Coaxial Cable, 30 m, with N-type / N-type Connectors
The 30-metre RG-8 coaxial cable with N-type/N-type connectors is designed for radio signal transmission systems where stability and moderate attenuation matter. The larger cable diameter and double shielding provide better signal quality than thinner alternatives.
The cable is suitable for antenna systems, FPV setups, repeaters and other radio equipment that requires reliable signal transmission.
Key Benefits of the RG-8 Cable
- moderate signal attenuation thanks to the solid Ø 2.74 mm centre conductor
- stable performance at frequencies up to 1.8 GHz
- effective interference shielding: aluminium foil (100%) + tinned copper wire braid (90%)
- reliable N-type/N-type connectors
- suitable for a wide range of radio systems
- durable PVC jacket
Applications
The cable is used in systems that require quality signal transmission and protection against interference.
- antenna communication systems
- FPV drones and ground stations
- radio relay systems
- repeaters and signal amplifiers
- telecommunications equipment
Cable Construction
| Inner conductor | solid copper-clad aluminium, Ø 2.74 mm |
| Dielectric | physically foamed polyethylene, Ø 7.24 mm |
| 1st shield | aluminium foil, 100% |
| 2nd shield | tinned copper wire braid, 90% |
| Outer jacket | polyvinyl chloride (PVC), black, Ø 10.16 mm |
Technical Specifications
| Cable type | RG-8 |
| Cable length | 30 m |
| Package contents | 2 cables of 30 m each, with connectors |
| Nominal characteristic impedance | 50 Ω (±3) |
| Capacitance per unit length | 84 pF/m |
| Nominal velocity of propagation | 85% |
| Maximum attenuation (at 20°C) | 50 MHz: 3.45 dB/100 m 150 MHz: 5.40 dB/100 m 300 MHz: 7.70 dB/100 m 500 MHz: 10.02 dB/100 m 900 MHz: 14.45 dB/100 m 1500 MHz: 19.15 dB/100 m 1800 MHz: 21.76 dB/100 m |
| Minimum bend radius | 10× cable diameter (approx. 102 mm) |
| Operating temperature range | -30°C ~ +70°C |
| Connector type | N-type / N-type |
Operating Notes
- avoid sharp bends and do not go below the minimum bend radius
- provides a stable signal at operating frequencies up to 1.8 GHz
- operates within a temperature range of -30°C to +70°C
- suitable for fixed installations and field use
Why Choose the 30 m RG-8
The 30 m RG-8 coaxial cable is a solution for building stable radio systems. It combines quality signal transmission and effective shielding, while the ready-fitted N-type connectors let you connect your equipment right away.
