MIWARS Electronic Warfare Uninterruptible Power Supply (2.5 kWh): Tactical Autonomy in the Field

In modern warfare, the effectiveness of electronic warfare (EW) systems directly depends on the stability and duration of their power supply. The 2.5 kWh MIWARS Uninterruptible Power Supply (UPS) is a specialized energy hub designed to ensure the continuous operation of powerful jamming stations. Thanks to LiFePO4 technology, this battery guarantees a stable output voltage and an enormous service life, even under the most extreme conditions.

Parameter	Characteristic value
Energy capacity	2500 Wh (105 Ah)
Battery type	LiFePO4 (Lithium iron phosphate)
Maximum load power	1000 W
Output voltage	28 V (stabilized)
Output connectors	XT90 (power, high-current)
Full charge time (220 V)	3 - 4 hours
Number of charge/discharge cycles	~ 2800
Dimensions and weight	460 x 210 x 390 mm / 23 kg

Why is this UPS critical for EW systems?

Powerful EW systems require significant energy consumption to create an effective protective dome. This power supply is designed to withstand high loads and ensure the operation of signal booster modules without voltage drops, which directly affects the drone suppression radius.

LiFePO4 (Lithium Iron Phosphate) Technology: The safest and most durable type of batteries. It is not prone to spontaneous combustion when mechanically damaged and maintains its capacity even under intensive use over a wide temperature range.

Colossal resource (2800+ cycles): Unlike conventional Li-ion batteries, LiFePO4 withstands 3-4 times more charge-discharge cycles, making it a profitable and reliable investment for a long service life.

Built-in Smart BMS (80-100 A): The battery management system (BMS) automatically protects cells from overcharge, deep discharge, and short circuit. This is critical when charging from unstable generators or inverters.

Tactical design: The housing in the form of a shockproof plastic case protects internal components from moisture, dust and impacts, and the ergonomic handle facilitates transportation when frequently changing positions.

Technical and tactical characteristics (TTX) of MIWARS 2.5 kW·h

Thanks to the output voltage of 28 V, this battery is ideally compatible with professional electronic warfare stations of the MIWARS series, providing maximum efficiency of signal amplifiers.

Parameter Characteristic value

Energy capacity 2500 Wh (105 Ah)

Battery type LiFePO4 (Lithium iron phosphate)

Maximum load power 1000 W

Output voltage 28 V (stabilized)

Output connectors XT90 (power, high-current)

Full charge time (220 V) 3 - 4 hours

Number of charge/discharge cycles ~ 2800

Dimensions and weight 460 x 210 x 390 mm / 23 kg

Ergonomics and ease of use in the field

The design of the UPS is thought out so that the operator does not need unnecessary equipment:

Built-in charger: For To charge the battery, you only need a cable to the 220 V network. There is no need to carry a separate, massive power supply unit - everything is already mounted inside the case.

High-speed XT90 connectors: Reliable connectors with a lock ensure stable contact even under strong vibration (for example, when installing on equipment).

Fast recharging: The ability to fully restore energy in 3-4 hours allows you to quickly prepare the system for the next combat sortie.

Expert opinion: This UPS model is the golden mean between weight (23 kg) and energy reserve. It allows you to maintain the operation of a 5-band dome electronic warfare system for several hours of continuous radiation at maximum power.

Protection and safety

The use of a BMS board for 80-100 Amperes allows The device can easily withstand the peak inrush currents of electronic warfare stations. The plastic case form factor not only simplifies logistics but also creates an additional thermal barrier for the batteries, which improves operation at low temperatures.

Conclusion:Guaranteed Stable Protection

The MIWARS 2.5 kWh Uninterruptible Power Supply for Electronic Warfare is the professional choice for those who don't compromise on security. High capacity, fast charging, and reliable LiFePO4 cells make this device an indispensable component of a comprehensive electronic defense system.

Tactical FAQ: Six Questions About the MIWARS 2.5 kWh UPS

What does a 2.5 kWh capacity really mean for electronic warfare?

That's 5 hours of continuous operation for a 5-band electronic warfare system. Ideal for evacuation or assault when using a generator or car network is not possible.

Why is this UPS better than a regular household station?

Direct DC output saves up to $20\%$ of the energy that in regular stations is spent on inverter operation. It also reduces the thermal footprint, making the position less visible to thermal imagers.

Is LiFePO4 safe under shelling?

LiFePO4 cells do not ignite even when penetrated by shrapnel or strong impact. This is a vital safety standard for working in a combat zone.

Protection from vibration and moisture?

The case is reinforced with dampers for off-road driving. All connectors are water-resistant and equipped with locks to prevent accidental cable disconnection.

Is LiFePO4 Safe Under Fire?

LiFePO4 cells do not ignite, even when punctured by shrapnel or subjected to strong impact. This is a vital safety standard for operation in a combat zone.

Vibration and Moisture Protection?

The case is reinforced with dampers for off-road driving. All connectors are water-resistant and equipped with latches to prevent accidental cable disconnection.

Is LiFePO4 Safe Under Fire?

LiFePO4 cells do not ignite, even when punctured by shrapnel or subjected to strong impact. This is a vital safety standard for operation in a combat zone.

Vibration and Moisture Protection?

The case is reinforced with dampers for off-road driving. All connectors are water-resistant and equipped with latches to prevent accidental cable disconnection.
